Peb Structure

Peb Structure
Peb Structure
Product Code : JCI0004
Product Description

Peb Structure

Being a customer based organization, we are engaged in manufacturing, supplying and exporting Peb Structure. This structure is made under the guidance of our skilled constructors, along with heavy load equipment and latest technology. Our offered product is available with us in different dimensions, sizes and other specifications. This structure is provided with 0.5mm total coated thickness and made up of hi-tensile galvalume steel, which is obtained from the credential vendors of the market. We provide this Peb Structure with weathering finish coat of RMP paint of 20 Micron, which is an added advantage.

Features:

  • Anti-siphoning
  • Weathering finish coat
  • High strength
  • Fine finish
Other specifications:
  • Zinc / Alum. Alloy coating: 150 gsm coating total of both side as per. As 1397
  • Yield strength: 550 Mpa.
  • Profile: 1010 mm & 1080mm with 28-30mm high crests at 250-255mm centers.
  • Side laps with special male/female side laps and anti-siphoning feature to prevent leakages.
  • Ridge / Flashing / Corner Piece in same profile available.
Hi-Rib Bare Galvalume Color Coated Sheet
  • Silicon/Zinc/Alum. Alloy coating mass: 43.5% Zinc & 55% aluminum & Zinc 1.5% tensile cold rolled steel as per AS 1397.Coating class AZ 150(min.150gsm/m2Zinc
  • Yield strength: 550 Mpa. Confirming to AS 1397/ASTM A792.
  • Weathering finish coat of RMP paint: 20 Micron.
  • Profile: 1080mm with 28-30mm high crests at 250-255mm centers.
  • Sheets shall be fixed by means of self-drilling self-trapping hot dip zinc costing climaseal polymer coated fasteners of 12X14X55mm long.
  • Ridge/Flashing/Corner Piece in same profile available.
Hi-Rib Galvanized Color Coated Sheet
  • Zinc/Alum. Alloy coating: 150 gsm coating total of both side as per. As 1397 Yield strength: 550 Mpa.
  • Weathering finish coat of RMP paint: 20 Micron.
  • Profile: 1010 mm & 1080mm with 28-30mm high crests at 250-255mm centers.
  • Side laps with special male/female side laps and anti-siphoning feature to prevent leakages.
  • Ridge/Flashing/Corner Piece in same profile available.
